Pelacak GPS multifungsi TK100 untuk truk, dengan interkom suara, pelacakan satelit, dan platform Google Maps

10PCS can be customized Your LOGO!

 Notice Before Order：

*This product uses 2G GSM network，If your 3G/4G/5G SIM CARD can also support 2G network, then it is ok to use. But if your country have closed 2G GSM network,We suggest you choose our 4G GPS tracker. These countries already closed 2G network: Australia, Japan, China Taiwan, Sourth korea, Singapore, Canada, New Zealand.

*If you are in Chile or Colombia, after you receive the product, you should register IMEI in your country as soon as possible, otherwise the device is not allowed to be used in your country.

*If you are in Turkey or Pakistan, you can note the valid IMEI number of the local country in the order request. We will modify it for you.

 Applicable

*Vehicle anti-theft

*Vehicle rental

*Fleet management

*Logistics transportation

*The Shared items

 Model Choose

 How To Instell It?

*It is recommended that the installation be performed by professional technicians.

*Please use the original accessories.

1.Device Installation Site

The device has built-in high-precisionGSM and GPS antenna, install needfront side upward and make sure there is no metal shielding.

2.Wires Connection:

1)4P cable’s red wire and relay’s white wire connect to vehicle battery positive +

2)4P cable’s black wire connects to vehicle battery negative -

3)4P cable’s yellow wire connects to relay’s yellow wire

4)4P cable’s green wire connects to ACC ignition wire

5)Relay: cut the oil pump line of the vehicle, and connect the two green wires of relay

6)Connect the accessories to the corresponding interface as shown in the picture

 How to log in mobile APP and web server?

1.Set APN

* Set the APN of device, then it will online tracking by platform

* If the device is already online after insert the SIM card, no need to set APN.

We have two ways to get the APN content of the device’s SIM card: Check the carrier on the internet or put the SIM card into cell phone to find out APN.

Set command:

#apn#123456#Apn Name#APN Account#Apn Password#

E. g:#apn#123456#tim#brtim#tim#

If no APN name and APN password, no need input,  E.g: #apn#123456#cmnet#

2.Website Tracking

Website: www.gps2828.com

Select “Plate no./IMEI”to login,IMEI/ID NO.:On the sticker of the device.

Password:123456

3.Applications for Android/IOS:

Search “secumoreplus”in the Apple/Google APP Store or Scan the QR Code to install the APP on your phone.

Use the IMEI/ID number to login.

Password:123456

4.Admin Account

If you need multi-devices management, you can contact our to create an admin account for your devices.
